| After-sales Service: | Yes |
|---|---|
| Warranty: | 25 Years |
| Number of Cells: | 132 PCS |
| Application: | Industrial |
| Condition: | New |
| Certification: | ISO, CE, TUV, Cec, IEC61215, IEC61730 |
| Samples: | US$ 180/Piece 1 Piece(Min.Order) | Request Sample |
|---|
| Customization: | Available | Customized Request |
|---|
Basic Info.
Model NO.
YS700M-66
Material
Monocrystalline Silicon
Frame
Anodized Aluminium Alloy
Junction Box
IP68 Waterproof
Solar Cell
Mono 210*105mm Half Cell
Front Cover
3.2mm High Transmission Low Iron Tempered Glass
Size
2400*1303*35mm
Connector
Mc4 Compatible Connector
Backsheet Color
White or Black or Transparent
OEM Order
Acceptable
Frame Color
Silvery or Black
Weight
36 Kg
Transport Package
by Carton & Pallet
Specification
2400*1303*35mm
Trademark
Yangtze Solar
Origin
China
HS Code
8541402000
Production Capacity
500000 Piece/ Years
Product Description
Model Type | YS660M-66 | YS670M-66 | YS680M-66 | YS690M-66 | YS700M-66 |
Rated Maximum Power at STC | 660W | 670W | 680W | 690W | 700W |
Maximum Power Voltage (Vmp) | 38.38V | 38.68V | 38.98V | 39.28V | 39.58V |
Maximum Power Current (Imp) | 17.20A | 17.33A | 17.45A | 17.57A | 17.69A |
Open Circuit Voltage (Voc) | 45.55V | 45.85V | 46.15V | 46.45V | 46.75V |
Short Circuit Current (Isc) | 18.45A | 18.54A | 18.66A | 18.79A | 18.92A |
Module Efficiency | 21.1% | 21.4% | 21.7% | 22.0% | 22.3% |
Working Conditions&Working Conditions | |||||
Operating Temperature | -40°c~ 85°c | ||||
Maximum System Voltage | DC 1000V(IEC) / 1500V(IEC) | ||||
Maximum Series Fuse | 25A | ||||
Power Tolerance | 0~ 5W | ||||
Temperature Coefficient of Pmax | -0.35%/°c | ||||
Temperature Coefficient of Voc | -0.29%/°c | ||||
Temperature Coefficient of Isc | 0.048%/°c | ||||
STC(Standard Testing Conditions): lrradiance 1000W/m2, Cell Temperature 25 'C, Spectra at AMl.5 | |||||
NOCT (Nominal Operating Cell Temperature): lrradiance 800W/m2, Ambient Temperature 20 'C, Spectra at AMl.5, Wind at l m/S | |||||
***** Factory Introduction *****
♦ Founded in 1994, 300MW solar panel production capacity, solar panel power range 3watt to 510watt for both polycrystalline and monocrystalline solar panel
♦ 10 years total workmanship and materials warranty, 10 years for at least 90% and 25 years for 80% linear power output warranty
♦ 100% EL test before package and shipping
♦ Two factories, solar panel factory, battery factory
♦ Cooperated with world-famous big companies like Jinko Solar , SMA,Tesla , HUAWEI
♦ Products are exported to more than 150 countries
♦ Products are certified by TUV(Germany),CE
♦ Turn-key solar systems are offered, to save time and money for the clients
♦ Rich experience in overseas construction of solar projects
